| Sr.No. |
Grade |
Filler Content by Weight(%) |
Standard Series |
Properties |
| 1 |
Virgin PTFE |
- |
Yes |
- Hygienic
- Excellent Chemical Resistance
- Outstanding electrical properties
|
| 2 |
Chemically Modified PTFE |
- |
Yes |
- Less Creep.
- Improved Permeation Resistance
- Smoother Surface
- Less Porous
- Better High Voltage Insulation
- New Fabricating Versatility with welding
|
| 3 |
Pigmented PTFE |
- |
No |
|
| 4 |
Glass filled PTFE |
15 - 25 |
Yes |
- High compressive strength
- Excellent chemical resistance
- Improved wear resistance under load & permanent deformation
|
| 5 |
Carbon / Coke filled PTFE (soft amorphous carbon hard fiber) |
25 - 35 |
Yes |
- High compressive strength
- Improved wear resistance under load & permanent deformation
- Better thermal / electrical conductivity
|
| 6 |
Graphite filled PTFE(pure crystalline carbon) |
15 |
Yes |
- High compressive strength
- Improved wear resistance under load & permanent deformation
- Better thermal / electrical conductivity.
- Good chemical resistance
- Improved frictional properties
|
| 7 |
Carbon + Graphite + Glass Filled |
12 + 3 + 10 |
Yes |
- High compressive strength
- Improved wear resistance under load & permanent deformation
- Better thermal / electrical conductivity.
|
| 8 |
Bronze filled PTFE(oxidising /Non oxidising) |
40 - 60 |
Yes |
- High compressive strength
- Excellent wear resistance improved under load & permanent deformation
- Better thermal / electrical conductivity.
- Good chemical resistance
- Very low cold flow
|
| 9 |
Bronze plus, Molybdenum Disulphide filled PTFE |
55 + 5 |
Yes |
- Improved fictional properties
- High compressive strength
- Excellent wear resistance improved under load & permanent deformation
- Good thermal / electrical conductivity.
- Very low cold flow
|
| 10 |
Aluminum Oxide filled PTFE |
5 - 10 |
Yes |
- Excellent electrical properties
- Excellent compressive strength
- Excellent wear resistance improved under load & permanent deformation
|
| 11 |
Calcium Fluoride filled PTFE |
5 - 10 |
No |
- Excellent chemical resistance
- Excellent wear resistance improved under load & permanent deformation
- Excellent compressive strength
- Good with chemicals that attack glass
|
| 12 |
Stainless Steel filled PTFE |
5 - 10 |
No |
- Excellent chemical resistance
- Outstanding mechanical properties
- Good wear resistance
|
| 13 |
Mica filled PTFE |
5 - 10 |
No |
- Excellent compressive strength
- Very low coefficient of thermal expansion
- Poor tensile properties
|
| 14 |
Glass + MoS2 filled PTFE |
5 + 10 |
Yes |
- High compressive strength
- Excellent chemical resistance
- Improved wear resistance under load & permanent deformation
- Improved frictional properties
|
| 15 |
MoS2 Filled PTFE |
0.1 - 0.2 |
No |
- Self-lubrication in presence of a Polar gas
- Low friction coefficient
- Retained high dielectric performance even in presence of improved thermal and electrical conductivity due to the filler
- Good dimensional stability and not fragile like ceramic
- Service temperature range from -272 up to +260℃
|
| 16 |
Peek Filled PTFE |
15 |
Yes |
- High compressive strength
- Excellent chemical resistance
- Outstanding mechanical properties at elevated temp.
- Good wear resistance
|
| 17 |
Borum Nitrite Filled PTFE |
10 |
No |
- Self-lubrication in presence of a Polar gas
- Low friction coefficient
- Retained high dielectric performance even in presence of improved thermal and electrical conductivity due to the filler
- Excellent compressive strength
- Service temperature range from -272 up to +260℃
|
| 18 |
Cobalt Aluminate Filled PTFE |
0.3 |
No |
- Self-lubrication in presence of a Polar gas
- Low friction coefficient
- Retained high dielectric performance even in presence of improved thermal and electrical conductivity due to the filler
- Very high compressive strength
- Service temperature range from -272 up to +260℃
|
